Automatic Flatbed
Precision Cutting Machine HQGZ-250P with Max Cut Capacity 60mm
Download Technical Data: Flatbed Precision Cutting Machine HQGZ-250P
Brief Introduction:
The iqualitrol HQGZ-250P precision flatbed cutting machine uses a touchscreen and PLC controller, providing stable performance and real-time display of cutting parameters.
The Y-axis automatically feeds during cutting, offering high positioning accuracy, a wide speed adjustment range, and strong cutting capability.
The cutting chamber adopts a fully enclosed design with a transparent protective cover for observation during cutting. It is equipped with a circulating cooling system, ensuring that the cut specimens have a bright, smooth surface without burning.
HQGZ-250P is especially suitable for precision cutting of materials such as PCBs, electronic components, ceramics, crystals, hard alloys, rocks and minerals, concrete, organic materials, and biological materials (teeth, bones), making it an ideal choice for a desktop automatic precision cutting machine.
Technical Specifications:
| Cutting Mode | Automatic feed in Y-axis (automatically returns to initial position after cutting) Manual feed Pulse feed (automatically returns to initial position after cutting) |
| Display | Touch screen |
| Hand Knob | to control movement of front and back |
| Feed Speed | 0-600mm/min (Step 0.01mm) |
| Cutting Disc | Φ250*2*Φ32mm |
| Rotation Speed | 500-3000rpm |
| Y axis Travel | 235mm |
| Cutting Capacity | Φ 60mm for cylinder sample |
| Power | 1000W |
| Program Store | 100 groups |
| Cutting Table | 450mm*530mm |
| Clamp | quick clamp and pressing plate clamp |
| vertical clamp length | 110mm |
| horizontal clamp width | 450mm |
| Cooling | Automatic water cooling |
| Power supply | AC220V/50Hz/1ph |
| Dimension | 620*730*420mm |
| Weight | 80Kg |
Main Functions and Features:
1, Touch screen display control, with a clear and intuitive interface, easy to operate;
2, The entire process is automatically closed-loop controlled, making touch screen operation more intuitive and convenient;
3, Equipped with built-in water cooling system for fast cooling;
4, Can store 100 sets of cutting process recipes for quick access, enabling serial production;
5, Equipped with quick clamps and pressing plate clamps made of SUS304;
6, The handle can control the cutting back and forth, or it can be controlled via the touch screen.
